Length (with bucket on ground) 3490 mm
Operating weight 3400 kg
Rated bucket capacity 0.53 m³
Simple and intuitive dual-joystick control
The loader is equipped with dual joysticks for both driving and loading functions, offering straightforward and reliable operation for users of varying experience levels.
All-wheel drive with skid steering
Delivers responsive control and maneuverability, particularly effective in confined areas or challenging terrain with tight obstacles and uneven surfaces.
Short wheelbase with high hydraulic power
Its compact frame improves stability and handling, while the high-performance hydraulic system provides strong power output, ideal for high-frequency, short-distance material transport operations.
Compatible with a wide range of attachments
Designed to support multiple tools including backhoe arms, vibrating ice breakers, pallet forks, mixing buckets, and augers, this model adapts to diverse tasks such as ice removal, material handling, drilling, and on-site mixing. For more details, please refer to the PDF.
Overall Dimensions
- Length (with bucket on ground) 3490mm
- Width (to outside of wheels) 1850mm
- Bucket width 1890mm
- Height(to the top of the cab) 2260mm
- Wheel base 1085mm
- Track width 1500mm
Performance
- Rated load 1050kg
- Operating weight 3400kg
- Rated bucket capacity 0.53m³
- Max. breakout force 27kN
- Static tipping load 20kN
- Max. dump clearance 2550mm
- Dump reach 700mm
- Dump angle at any position >40
- Angle of departure 30°
- Min. turning radius Outside of bucket
Outside of front wheel
Outside of frame tail 2230mm
1204mm
1706mm - Lifting time of bucket ≤4.2sec.
- Lowering time of bucket ≤2.5sec.
- Dumping time ≤2.6sec.
- Travel speed Forward (1 gear)
Reverse (1 gear) 0-12km/h
0-12km/h
We understand that dependable service matters just as much as quality equipment. That’s why we offer a range of flexible support options tailored to different needs:
Around-the-clock remote assistance, along with on-site visits, when necessary, to ensure fast and effective issue resolution.
A network of central warehouses overseas helps guarantee a steady supply of spare parts, with multiple service channels available to meet various post-sales requests.
Skilled service engineers based abroad are available to provide hands-on training, supported by complete technical and instructional resources prepared by our headquarters.
