255G Wheeled Skid Steer Loader

255G Wheeled Skid Steer Loader
  • 255G Wheeled Skid Steer Loader
  • 255G Wheeled Skid Steer Loader
  • 255G Wheeled Skid Steer Loader
  • 255G Wheeled Skid Steer Loader
  • 255G Wheeled Skid Steer Loader

    • 255G Wheeled Skid Steer Loader

    Designed for compact job sites, this wheeled skid steer loader delivers agile performance with a 750kg rated load and 0.43m³ bucket capacity. Powered by an engine with 36.7kW rated power, it delivers reliable handling and 11.5km/h travel speed. Its heavy-duty traction and breakout force ensure efficient handling across light construction, landscaping, and material transport tasks.

    • Operating weightOperating weight 2800 kg
    • Dimensions (L×W×H)Dimensions (L×W×H) 3320×1530×2000 mm
    • Rated powerRated power 36.7 kW/2500 rpm
    Request a Quote
    Product Brochure
    255G
    • Features
    • Specifications
    • Service
    • Request a Quote
    Main Features
    255G Wheeled Skid Steer Loader

    Optimized chassis design
    The combination of a narrow frame, long wheelbase, and high undercarriage enhances machine balance and maneuverability, with a smaller turning radius for efficient operation in tight spaces.

    255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader

    Quick-attach system with broad compatibility
    Equipped with an industry-standard quick coupler and hydraulic connectors compatible with most mainstream attachments, enabling fast and efficient tool changes.

    255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader 255G Wheeled Skid Steer Loader

    Safe and intuitive hydraulic control system
    The hydraulic operation system integrates electric interlock and self-locking features to prevent accidental engagement and ensure safer machine handling.

    255G Wheeled Skid Steer Loader

    FOPS/ROPS-compliant cab for enhanced operator comfort
    Built with a high-strength cab that meets international rollover and falling object protection standards, offering a more spacious and comfortable working environment.

    Technical Specifications

    General

    • Operating weight 2800kg
    • Rated load 750kg
    • Bucket capacity 0.43m³
    • Tipping load 1504kg
    • Breakout force 20.3kN
    • Traction force 18.9kN
    • Dimensions (L×W×H) 3320×1530×2000mm

    Engine

    • Engine model Xinchai
    • Rated power 36.7kW/2500rpm
    • Displacement 3.168L
    • Fuel consumption 10.6L
    • Stroke 98mm
    • Bore 105mm
    • Emission NationⅡ

    Hydraulic System

    • Hydraulic flow 74L/min·2500rpm
    • Operation method Pilot operation
    • Hydraulic pressure 21MPa

    Drivetrain

    • Travel speed F&R 11.5km/h
    • Tire 10-16.5NHS

    Accumulator

    • Voltage 12V
    • Capacity 120Ah

    Tank Capacity

    • Chain box 2×9L
    • Cooling system 12L
    • Engine crankcase 8L
    • Fuel tank 83L
    • Hydraulic tank 65L
    After-Sales Support

    We understand that dependable service matters just as much as quality equipment. That’s why we offer a range of flexible support options tailored to different needs:

    After-Sales Support
    1

    Around-the-clock remote assistance, along with on-site visits, when necessary, to ensure fast and effective issue resolution.

    After-Sales Support
    2

    A network of central warehouses overseas helps guarantee a steady supply of spare parts, with multiple service channels available to meet various post-sales requests.

    After-Sales Support
    3

    Skilled service engineers based abroad are available to provide hands-on training, supported by complete technical and instructional resources prepared by our headquarters.

    Equipped with all-terrain tires or tracked undercarriages and four-wheel drive, skid steer loaders deliver strong stability and performance across uneven ground. Some models also feature hydraulic suspension systems that automatically adjust ground clearance to suit the terrain.

    Oil-bath air filters provide multi-layer filtration using lubricating oil to trap dust and particles, offering efficiency above 98%. This option is ideal for high-dust environments such as mining sites or construction zones, where it helps reduce engine wear and extend service life.

    Skid steer loaders are valued for their compact size, high maneuverability, independently driven wheels or tracks, high-mounted boom arms, wide attachment compatibility, and powerful engines paired with efficient hydraulic systems.

    Most skid steer loaders are designed with universal mounting plates compatible with attachments from different brands. However, compatibility and safety must be confirmed before use.

    Yes, but slope operation requires proper training and safety precautions. The machine should be equipped with suitable tires or tracks to maintain traction and stability on inclined terrain.
